Home › Products › Chicken layer cage › D Type Layer Cage
Click to enlargeLAYER CAGE · 3 / 4 TIERS
D Type Layer Cage
A deeper cage body than the standard H-type, giving each bird more floor area per tier while keeping the footprint compact — a middle-ground choice between raw density and bird comfort.
- Tiers
- 3 / 4
- Birds per set
- 100–180
- Suits
- 5,000–20,000 birds
Where D-type fits
- Deeper floor. More floor area per bird than a standard H-type cage of the same width, without giving up vertical stacking.
- Bird welfare. The extra depth gives hens more room to move, which some markets and certification schemes now expect.
- Automatic manure handling. A belt under every tier, same as the H-type, keeping ammonia controlled and manure dry.
- Density trade-off. Fewer birds per square metre than a standard H-type, more than an A-type.
Specifications
D-Type Technical Parameters
| Model | Tiers | Birds Per Set | Dimensions (L×W×H) | Galvanization Standard | Suits |
|---|---|---|---|---|---|
| SX-D3 | 3 tiers | 100 birds | 1950 × 2250 × 1750 mm | Hot-dip galvanized 275g/m² | 5,000 – 10,000 |
| SX-D4 | 4 tiers | 140 birds | 1950 × 2250 × 2250 mm | Hot-dip galvanized 275g/m² | 10,000 – 20,000 |
